Category: Hammers

Part Number: 740.100.010

SR740 Hammer Assembly

50 in stock

Category: SKU: 740.100.010

SR740 Hammer Assembly
SREPS Reverse Circulation Hammers heavy-duty design allows the hammer to be reliable in all conditions, as well as increase your drilling efficiency.

Hammer outside diameter: 116mm (4.6″)
Bit range size: 124mm-137mm (4-7/8″ – 5-3/8″)
Hammer weight: 59kg (130lbs)
Hammer length: 1023mm (40.3″)
Piston weight: 13kg (28.7lbs)



Key Features
* Simple, elegant design
* Low part count
* Easy to maintain
* High performance
* Excellent value

Additional information

Weight 66.8 kg
Dimensions
Width: 186mm
Height: 219mm
Depth: 1170mm
